Display Circuit Board Auxiliary LED
A LED is provided in the kit for optional installation on the display board. This new LED
allows the processor's program to provide additional state information during the radio's
operation. Note that it is not required to install this extra LED for the kit's operation. Refer to
the Ten-Tec instruction manual page 1245 - Assembly - 7. The new LED inserts in between
diode D5 and D6 in the same orientation in the holes present but unlabeled on the display board.
