А
and
МЕО
В
displays
will
now
exchange
contents,
each
transferring
its
frequency
and
mode
to
the
other
one.
A=B
copies
the
МЕО
A
frequency
and
mode
to
the
VFO
B
register.
2.4.7.
Lock
Button
Pushing
the
LCK
button
locks
the
main
tuning
to
prevent
disturbing
JUPITER's
frequency
by
inadvertent
movement
of
the
knob.
А
nearby
red
LED
lights
when
the
frequency
is
locked.
Push
LOCK
again
to
re-activate
the
tuning
knob.
2.4.8.
RIT
&
ХІТ
Buttons
Alternate
presses
of
Ше
RIT
button
activate
or
disable
the
RIT/XIT
(Receiver
/
Transmitter
Incremental
Tuning)
control.
In
the
active
RIT
state,
the
control
offsets
the
receiver
frequency
from
that
in
the
VFO
A
display
without
changing
the
transmit
frequency.
The
control
has
a
+/
10
kHz
range.
The
setting
appears
at
the
right
of
the
display
under
the
VFO
A
frequency
range.
RIT
is
normally
off.
XIT
offsets
the
transmit
frequency
from
that
in
the
VFO
A
display
without
changing
the
receive
frequency.
Otherwise
it
works
the
same
as
RIT
and
is
normally
off.
JUPITER
will
activate
only
one
of
the
Incremental
Tuning
modes
at
a
time.
2.4.9,
Mode
Selection
JUPITER
transceives
in
USB,
LSB,
CW,
AM
and
FM
modes
within
the
160
through
10-meter
amateur
bands.
Use
either
USB
or
LSB
as
appropriate
for
the
digital
modulation
modes
(RITY,
AMTOR,
PSK31,
PACTOR,
et
cetera).
Select
the
modulation
mode
by
repeated
presses
of
the
MODE
button
until
the
desired
mode
shows
on
the
display
to
the
left
of
the
VFO
A
readout.
2-6
2.4.10.
VFO
Operation
JUPITER
has
two
tuning
registers
or
“VFOs”,
each
of
which
displays
and
holds
an
operating
frequency
and
mode.
The
larger
(main)
display
is
VFO
A.
VFO
B
is
the
smaller
(alternate)
display.
To
the
left
of
each
VFO
readout
is
one
of
the
following
legends:
RxTx,
Rx,
Tx,
or
a
blank.
They
keep
the
operator
aware
of
which
VFO
is
active
in
receive
and
transmit
states.
Before
transmitting,
it
is
wise
to
note
which
frequency
the
active
transmit
VFO
holds.
2.4.11.
Split
Operation
Example
When
the
SPLIT
mode
is
active,
the
receiving
frequency
and
mode
are
in
the
A
display
(marked
Rx)
and
the
transmitting
frequency
and
mode
are
in
the
B
display
(marked
Tx).
Pressing
SPLIT
again
restores
the
RxTx
designator
to
VFO
A
and
leaves
VFO
B
with
inactive
status.
For
example:
a
DX
station
5
transmitting
on
14.195
and
listening
for
calls
around
14.200.
Tune
the
VFO
А
display
frequency
to
the
calling
frequency
near
14.200.
Tap
the
A=B
button
to
equalize
both
VFOs
at
14.200.
Tap
the
SPLIT
key.
Now
retune
VFO
A
to
the
DX
at
14.195.
МЕО
A
now
controls
the
receive
frequency.
VFO
B
controls
your
transmit
frequency
and
you
are
ready
to
join
the
action.
2.4.12.
Reverse-Split
Example
With
JUPITER
іп
SPLIT-frequency
operation,
the
momentary-action
REV
key
exchanges
the
frequency
and
mode
between
VFOs
A
and
B
while
you
press
it.
REV
is
a
convenient
operating
aid
in
situations
such
as
the
one
below.
74269
Second
Printing
Model
538
JUPITER
30
August,
2001
