10-24
TABLE 10-3 81817 SMD 2
ND
MIXER PARTS LIST
I.D. Description
Part
No.
C36
C45, C8
C10, C35, C37
C11, C28
C29, C30, C31, C32, C54, C55, C65
C57
C53, C62
C7, C63
C15, C18, C33, C48, C75
C6
C1, C9, C14, C16, C17, C20, C23, C24, C34, C56
C21, C41, C42, C43, C44, C46, C51, C52, C58, C64, C68, C69, C71, C72, C78,
C79.
C7
C5
C73
C2, C13, C19, C22, C25, C26, C38, C39, C47, C49, C50, C61, C66, C70, C77.
C3, C27, C40, C59, C60, C74, C76
C3A, C27A, C40A, C59A, C6OA, C74A, C76A
(REPLACES C3, C27, C40, C59, C60, C74, C76)
C4
D2, D7, D8, D10
D3, D4, D5, D6, D9
D11
FL1, FL2
L2, L3, L5
L1
L4
L6
Q1, Q2, Q5, Q8, Q9, Q14, Q15, Q17
Q3, Q4, Q6, Q16
Q7
Q10, Q11, Q12, Q13
R34
R5, R19, R20, R29, R30, R54, R68, R107
R35, R36, R37, R38, R39
R18, R42, R53, R57, R58, R100
12 pF
27 pF
33 pF
47 pF
100 pF
220 pF
470 pF
2200 pF
.01 µF
.01 µF
.001 µF
0.1 µF
.l µF
.47 µF
1/20
1/16
10/16
10/25
100/35
MMSD914T1
BAT68_04
SVC321SPA
455FILT
.33 µH
.39 µH
1.5 µH
820 µH
MMBT3904LT1
MMBT3906LT1
2SC1971
MMBFJ310LT1
10 3/4W
10
33
47
23463
23467
23468
23470
23474
23478
23482
23498
23487
23340
23486
23488
23328
23330
23264
23524
23525
23266
23189
28124
28132
28099
48203
21216
21107
21224
21095
25375
25376
25337
25377
30022
30638
30644
30646
