Tenda AC8 User Manual

6
Port & Button
Port/Button
Description
POWER
Power jack.
Used to connect to the included power adapter.
WAN
10/100/1000 Mbps auto-negotiation WAN port.
⚫
(Default) Under the Router mode, connect this port to a modem or an Ethernet jack.
⚫
Under the WISP or Universal Repeater mode, DO NOT connect any device to this port.
⚫
Under the AP mode, it functions as a LAN port.
1, 2
10/100/1000 Mbps auto-negotiation LAN ports.
Used to be connected to computers, switches or game machines.
IPTV/3
10/100/1000 Mbps auto-negotiation Ethernet port.
It is a LAN port by default. When the IPTV function is enabled, it can only serve as an IPTV
port to be connected to a set top box.
WPS/RST
Used to start the WPS negotiation process, or to reset the router.
⚫
WPS: Press the button, and the WiFi LED indicator blinks slowly. Within 2 minutes,
enable the WPS function of the other WPS-supported device to establish a WPS
connection.
⚫
Reset: When the SYS LED indicator blinks, hold the button down for about 8 seconds,
and then release it when all the LED indicators light up. The router is restored to factory
settings.

Tenda AC8 Specifications

General

DSL WAN	No
Ethernet WAN	Yes
Product type	Tabletop router
Product color	Black
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
Ethernet LAN (RJ-45) ports	4
Antenna gain level (max)	6 dBi
Output current	1 A
Output voltage	9 V
AC input voltage	200 - 240 V
Power source type	AC
AC input frequency	50 - 60 Hz
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN data transfer rate (first band)	300 Mbit/s
WLAN data transfer rate (second band)	867 Mbit/s
Firewall security	Forbid WAN PING from internet
Security algorithms	WPA, WPA-PSK, WPA2, WPA2-PSK
Certification	CE, FCC, CCC, SRRC
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Cables included	LAN (RJ-45)
Package type	Box
Number of products included	1 pc(s)
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	127 mm
Width	200 mm
Height	33.6 mm
