Tenda AC8 User Manual

34
5 Wireless settings
5.1 WiFi name and password
5.1.1 Overview
On this page, you can configure basic WiFi parameters, such as the WiFi name and password.
To access the configuration page, log in to the web UI of the router, and navigate to Wireless
Settings > WiFi Name and Password.
Parameter description
Parameter
Description
Preferred Band
It is used to turn on or off the Preferred Band function.
When it is enabled, the WiFi names of 2.4 GHz and 5 GHz networks are integrated, and
only one WiFi signal is shown. Devices connected to the WiFi network will use the
network with better connection quality automatically.
WiFi Network
It is used to enable or disable the WiFi networks of the router.
2.4 GHz Network
You can enable or disable the 2.4 GHz network and 5 GHz network separately when
the Preferred Band function is disabled.
⚫
If the wireless devices such as mobile phones are far away from the router, or
blocked from the router by a wall, it is recommended to connect to the 2.4 GHz
network.
⚫
If the wireless devices are close to the router, it is recommended to connect to the 5
GHz network.
5 GHz Network
WiFi Name
It specifies the WiFi network name (SSID) of the WiFi network.

Tenda AC8 Specifications

General

DSL WAN	No
Ethernet WAN	Yes
Product type	Tabletop router
Product color	Black
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
Ethernet LAN (RJ-45) ports	4
Antenna gain level (max)	6 dBi
Output current	1 A
Output voltage	9 V
AC input voltage	200 - 240 V
Power source type	AC
AC input frequency	50 - 60 Hz
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN data transfer rate (first band)	300 Mbit/s
WLAN data transfer rate (second band)	867 Mbit/s
Firewall security	Forbid WAN PING from internet
Security algorithms	WPA, WPA-PSK, WPA2, WPA2-PSK
Certification	CE, FCC, CCC, SRRC
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Cables included	LAN (RJ-45)
Package type	Box
Number of products included	1 pc(s)
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	127 mm
Width	200 mm
Height	33.6 mm
