Wireless Modem Router User Guide
_________________________________________________________________________________________________
Tip:
For tagged service, enter valid 802.1P Priority and 802.1Q VLAN ID.
For untagged service, set -1 to both 802.1P Priority and 802.1Q VLAN ID.
_________________________________________________________________________________________________
4.3 Wireless
This section explains the following information:
Basic
Security
MAC Filter
Wireless Bridge
Station Info
4.3.1 Basic
This page allows you to configure basic features of the wireless LAN interface. You can enable or disable the wireless
LAN interface, hide the network from active scans, set the wireless network name (also known as SSID) and restrict the
channel set based on country requirements.
Click Apply/Save to configure the basic wireless options.
Enable Wireless: check/uncheck to enable/disable the wireless feature.
SSID: This is thepublic name of your wireless network.
Hide SSID (Hide Access Point): This option allows you to have your network names (SSID) publicly broadcast or
if you choose to enable it, the SSID will be hidden.
BSSIDDisplay the BSSID.

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Tenda D301 and is the answer not in the manual?

Tenda D301 Specifications

General IconGeneral
Ethernet LANYes
Cabling technology10/100Base-T(X)
Networking standardsIEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.1Q, IEEE 802.3, IEEE 802.3u
Ethernet LAN data rates10, 100 Mbit/s
Ethernet LAN interface typeFast Ethernet
Equivalent Isotropically Radiated Power (EIRP) (@IEEE 802.11n)20 dBmW
Wi-Fi bandSingle-band (2.4 GHz)
Wi-Fi standards802.11b, 802.11g, Wi-Fi 4 (802.11n)
Channel bandwidth40 MHz
Channels quantity13 channels
Top Wi-Fi standardWi-Fi 4 (802.11n)
WLAN data transfer rate (max)300 Mbit/s
Memory card slot(s)No
RJ-11 ports quantity1
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN (RJ-45) ports4
Data link protocols6RD, DS-Lite, IPv6, IPv4 dual stack
Antennas quantity2
Antenna gain level (max)5 dBi
Security algorithms64-bit WEP, 128-bit WEP, SSID, WPA-PSK, WPA2-PSK, WPS
Product typeTabletop router
Product colorWhite
LED indicatorsDSL, System, USB, WAN, WLAN, WPS
Output current1 A
Output voltage9 V
AC input voltage100 - 240 V
Power source typeDC
AC input frequency50 - 60 Hz
Storage temperature (T-T)-40 - 70 °C
Operating temperature (T-T)0 - 40 °C
Storage relative humidity (H-H)5 - 90 %
Operating relative humidity (H-H)10 - 90 %
CertificationG.994, ANSI T1.413, ITU-T G.992.1, ITU-T G.992.2, ITU-T G.992.3, ITU-T G.992.5, CE, FCC, RoHS
Cables includedLAN (RJ-45), Phone (RJ-11)
Harmonized System (HS) code85176990
Weight and Dimensions IconWeight and Dimensions
Depth105.2 mm
Width157.8 mm
Height29.4 mm
