Tenda F6 User Manual

57
Local upgrade

To enable your router is upgraded successfully, ensure that the firmware used to upgrade the
firmware is applicable to the router.

When you are upgrading a firmware, do not power off the router.
Step 1 Go to www.tendacn.com, download a firmware version of the router to your computer
and unzip it.
Step 2 Choose Administration, move to Device Management module to access the configuration
page.
Step 3 Click Local Upgrade.
Step 4 Select the corresponding firmware version. click Open.
Step 5 Click OK on the dialog box that appears.
---End
Wait until the progress bar is complete. Log in to the web UI of the router again. Choose Status >
System Information and check whether the upgrade is successful based on Firmware Version.
For better performance of the new firmware, when the upgrading completes, you are recommended to
reset the router to factory default settings and re-configure the router.
Online upgrade
When the router is connected to the internet, system will detect whether there is a new firmware

Tenda F6 Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.3, IEEE 802.3u
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Antennas quantity	4
Antenna gain level (max)	5 dBi
Product type	Tabletop router
Product color	White
LED indicators	WLAN
Wi-Fi band	Single-band (2.4 GHz)
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
WLAN data transfer rate (max)	300 Mbit/s
Frequency band	2.4 GHz
Firewall security	Support Oray.com，88ip
Security algorithms	WPA, WPA-PSK, WPA2, WPA2-PSK
Cables included	LAN (RJ-45)
Certification	CCC, CE
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
DSL WAN	No
WAN connection type	RJ-45
Power source type	DC
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	211 mm
Width	204 mm
Height	147.5 mm
