Tenda i27 Quick Installation Guide

Tips
− When you need to configure multiple APs in the LAN, to avoid IP address
conflict, connect and configure one AP (including the change of IP
address) first, then repeat the steps to configure other APs.
− Record the changed IP addresses of APs for later management.
Method one: through a Tenda hardware
controller
Method two: through the web UI of the AP
Configure the AP
If there is a Tenda hardware controller (a Tenda AP controller or a
Tenda router with AP management function) in the LAN, you can
manage the APs in batches through the hardware controller. For
details, please refer to the hardware controller’s user guide.
❶ Use an Ethernet cable to connect a management computer to
the AP or a switch which is connected to the AP.
❷ Set the IP address of the management computer to the same
network segment as that of the AP (default: 192.168.0.254).
For example, when the AP’s IP address is 192.168.0.254, you
can set the IP address of your computer to 192.168.0.X (X
ranges from 2 to 253 and is not occupied by other devices) and
subnet mask to 255.255.255.0.
If you do not have a controller in your network, you can configure
the AP on its web UI.
- 8 -
192.168.0.10
255.255.255.0

Tenda i27 Specifications

General

Antenna type	External
Antennas quantity	2
Antenna gain level (max)	4 dBi
2.4 GHz	Yes
MIMO type	Multi User MIMO
Number of users	254 user(s)
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11k, IEEE 802.11n, IEEE 802.11v, IEEE 802.3at
Virtual LAN features	Tagged VLAN
Spread spectrum method	OFDMA
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	2976 Mbit/s
Maximum data transfer rate (5 GHz)	2402 Mbit/s
Maximum data transfer rate (2.4 GHz)	574 Mbit/s
Power consumption (max)	14.04 W
Placement	Ceiling, Wall
Product color	White
Security algorithms	SSID, WEP, WPA, WPA-PSK, WPA2, WPA2-PSK
Number of SSID supported	8
Service Set Identifier (SSID) features	Hidden SSID
Storage temperature (T-T)	-30 - 70 °C
Operating temperature (T-T)	-10 - 45 °C
Operating relative humidity (H-H)	10 - 90 %
USB 2.0 ports quantity	-
Ethernet LAN (RJ-45) ports	1

Weight and Dimensions

Depth	38 mm
Width	178 mm
