Tenda i27 Quick Installation Guide

Tips
Tips
Install the AP
❶
− Record the MAC address (on the label) and installation position of the AP, so
that you can locate the AP through the MAC address.
− You may need a marker, a hammer drill, a drill bit, a rubber hammer, a
screwdriver, and a ladder for the installation. Please prepare them yourself.
− The AP is suitable for mounting at heights > 2 m.
Position the bracket on the ceiling and mark screw holes with
the marker.
❷
Drill holes in the marked positions using a hammer drill.
Option A applies to general cases. For ceilings with weak strength (such as
plasterboard), please choose Option B.
- 4 -

Tenda i27 Specifications

General

Antenna type	External
Antennas quantity	2
Antenna gain level (max)	4 dBi
2.4 GHz	Yes
MIMO type	Multi User MIMO
Number of users	254 user(s)
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11k, IEEE 802.11n, IEEE 802.11v, IEEE 802.3at
Virtual LAN features	Tagged VLAN
Spread spectrum method	OFDMA
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	2976 Mbit/s
Maximum data transfer rate (5 GHz)	2402 Mbit/s
Maximum data transfer rate (2.4 GHz)	574 Mbit/s
Power consumption (max)	14.04 W
Placement	Ceiling, Wall
Product color	White
Security algorithms	SSID, WEP, WPA, WPA-PSK, WPA2, WPA2-PSK
Number of SSID supported	8
Service Set Identifier (SSID) features	Hidden SSID
Storage temperature (T-T)	-30 - 70 °C
Operating temperature (T-T)	-10 - 45 °C
Operating relative humidity (H-H)	10 - 90 %
USB 2.0 ports quantity	-
Ethernet LAN (RJ-45) ports	1

Weight and Dimensions

Depth	38 mm
Width	178 mm
