Tenda O1 User Manual

156
----End
Parameters description
Name
Description
DDNS
It Specifies whether to enable the DDNS function.
Service Provider
It specifies Dynamic Domain Name Service provider. The device supports Dyndns,
No-ip.com, and 3322.org.
User Name
It specifies the user name used to log in to the dynamic DNS service, as well as the
login user name and password you registered on the website of the service provider.
Password
Domain Name
It specifies the domain name information obtained from the dynamic DNS server. You
need to enter the domain name which you registered on the website manually.
Example of configuring DDNS
Networking requirement
The device is used to bridge to the ISP hotspot for internet access in a house in the countryside,
and the device is set to WISP mode. The WAN IP address of the device is dynamic.
Requirement: The administrator on business can visit the resources on web server in LAN.
You are recommended to use the DDNS and port forwarding functions to solve the problem.
Assume that:
The information of the web server in LAN is shown as follows:
− IP Address: 192.168.2.100
− Service Port of the Web Server: 80

Tenda O1 Specifications

General

5 GHz	No
Bandwidth	2.4 GHz
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Maximum data transfer rate	300 Mbit/s
Placement	Wall
Certification	FCC/CE/RoHS
Product color	White
LED indicators	LAN, PoE, WLAN
International Protection (IP) code	IP64
Output voltage	9 - 12 V
Power consumption (max)	2.6 W
Security algorithms	WEP, WPA-PSK, WPA2-PSK
USB 2.0 ports quantity	0
Ethernet LAN (RJ-45) ports	1
Antenna features	Integrated antenna
Cables included	LAN (RJ-45)
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	-30 - 55 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	67.5 mm
Width	80 mm
Height	190.35 mm
