Tenda O1 User Manual

165
----End
Parameters description
Name
Description
SNMP Agent
It specifies whether to enable the SNMP agent function of the CPE. By default, it
is disabled.
An SNMP manager and the SNMP agent can communicate with each other only if
their SNMP versions are the same. Currently, the SNMP agent function of the
device supports SNMP V1 and SNMP V2C.
Device Name
It specifies the device name of the device. The default device name is the model
and version number of the device. For example, the default name of this device is
O2V1.0
It is recommended that you change the device name so that you can easily
identify the device when managing it using SNMP.
Read Community
It specifies the read password shared between SNMP managers and this SNMP
agent. The default password is public.
The SNMP agent function of the device allows an SNMP manager to use the
password to read variables in the MIB of the device.
Read/Write Community
It specifies the read/write password shared between SNMP managers and this
SNMP agent. The default password is private.
The SNMP agent function of the device allows an SNMP manager to use the
password to read/write variables in the MIB of the device.
Location
It specifies the location where the device is used. You can change the location as
required.

Tenda O1 Specifications

General

5 GHz	No
Bandwidth	2.4 GHz
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Maximum data transfer rate	300 Mbit/s
Placement	Wall
Certification	FCC/CE/RoHS
Product color	White
LED indicators	LAN, PoE, WLAN
International Protection (IP) code	IP64
Output voltage	9 - 12 V
Power consumption (max)	2.6 W
Security algorithms	WEP, WPA-PSK, WPA2-PSK
USB 2.0 ports quantity	0
Ethernet LAN (RJ-45) ports	1
Antenna features	Integrated antenna
Cables included	LAN (RJ-45)
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	-30 - 55 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	67.5 mm
Width	80 mm
Height	190.35 mm
