8
Rotary Switch
The table below provides information about rotary switch
positions.
Rotary
Switch
Position
Function
V DC voltage measurement range from 400.0mV to
1000V or
AC voltage measurement range from 4.000V to
750.0V.
Continuity test.
Diode test.
Resistance measurement range from 400.0
Temperature in celsius
Hz Frequency measurement range from 10.00Hz to
10.00MHz.
AC or DC current measurement range from
A.
mA AC or DC current measurement range from
40.00mA to 400.0mA.
A AC or DC current measurement range from
4.000A to 10.00A.
to 40.00M .
Model 72-7740/72-7745: OPERATING MANUAL
