TM-12E/13E/13R
EN-11
12. In order to avoid reading incorrect data, you have to
replace the batteries immediately when the symbol
BAT appears on the LCD.
13. Do not touch the circuit board before you take any
adequate action, and thus prevent from any
damage of contamination and static electricity.
4.2. AC CURRENT (ACA) MEASUREMENT
Make sure that all the test leads are disconnected
from the meter’s terminal for current measurement.
1. Select “~A” range.
2. Open the clamp and put the tested conductor in the
center of the clamp jaws (see Fig.2).(No gap is
allowed between the connections of clamp jaws)
3. The current value will be indicated on the LCD.
4. If the reading is difficult, press the DATA HOLD
button to hold the obtained value. To exit from this
function press DATA HOLD button again.
Fig. 2
