TX-1 Series Instrument www.tensitron.com pg. 13
o View Data Log
When data is logged to the instrument memory, that data and the
statistics of that data log (Count, Average, Minimum/Maximum, and
Standard Deviation) can be seen under the Data Logging / View Data
Stats screen. To view this logged data:
▪ Scroll to DATA LOGGING and press ENTER.
▪ Scroll to VIEW DATA LOG and press ENTER.
o Clear Single Point Log
To clear stored data, scroll to CLEAR SINGLE PT LOG, press ENTER,
and follow the prompts.
• TENSION UNITS Screen
To change the unit of measure in which tension readings are logged:
o Scroll to Tension Units and press ENTER.
o Use the Up and Down arrows to Grams, Newtons and Pounds
(CentiNewtons on TX-125 only) and press ENTER.
• SELECT MATERIAL Screen
Press ENTER while this display is shown to show the available options for
material types. The options are Wires, Filaments and Custom. Use the up or
down arrow to scroll to the option you want and press ENTER to select it.
o Select Material Wire Units
This feature allows the operator to select the unit for describing diameter
of wire to be measured for tension: AWG, Inches or mm.
o Select Material Filaments Units
This feature allows the operator to select the unit for describing diameter
of filaments to be measured for tension: Inches or mm.
o Select Material Custom Units
This feature allows the operator to select the unit for describing diameter
of the custom material to be measured for tension. For Custom, the
operator inputs the options for units. Use the up and down arrows to
scroll through all the available alpha-numeric symbols and press ENTER
to choose that symbol.
• LENGTH Screen
Scroll down to this screen to view the length that has traveled through the meter
since enabled (or reset), measuring up to 9,999 meters. The units of measure
will be shown in meters or feet. (These units are designated in the Setup screen
under Length Units).
• SPEED Screen
Scroll down to this screen to view the speed at which the material is passing
through the meter at that instant. The meter will also store the Minimum and
Maximum speeds logged. The units of measure will be shown in Meters/Minute
or Feet/Minute. (These units are designated in the Setup screen under Length
Units). Maximum measurable speed is 9,999 FPM or 9,999 meters per minute.
Note: line speeds exceeding 2,000 FPM are generally unsafe for hand-held
applications.
