3
03
Adjust the direction of the
headset, and use the No.5 Hex
Key to tighten the screws at the
stem and front fork (with 5–6
Nm torque).
04
The height of the handlebar can
be adjusted by with the No.6
Hex Key.
Please remember to tighten
back the bolt after adjustment
(with 20-25 Nm torque).
Tools needed: No.5 Hex Key
and No.6 Hex Key
No.6 Hex Key
2
1
01.
INSTALL THE HANDLEBAR
009
