3
1
2
01
Loosen the nut and remove the
quick release lever.
02
Remove all wrapping material
from the quick release.
03
Install the quick release on the
front wheel in the direction
shown in the figure, and then
tighten the nut.
Note: There is no need for you to
fully tighten the nut at this time.
Note:
When installing the quick
release spring, ensure that the
direction is the same as when it
was removed.
012 Assemble your TENWAYS e-bike
04.
PRE-INSTALL THE QUICK RELEASE
