Teradek RT - MDR-ACI and Controller Pairing; Wireless Pairing Procedures; Wired Pairing Procedure

7
Wireless Pairing via Controller
Connect a 5-pin connector from the controller’s wired-mode input to the AUX 1 input (J) on
the MDR-ACI. The controller and receiver will remain paired even after disconnecting the 5-pin
connector. The LED on the controller will turn blue once paired.
Wired Pairing
PAIR MDR-ACI AND CONTROLLER
Wireless Pairing via MDR-ACI
Press the Menu button on MDR-ACI, then navigate to MDR Settings>Port IN-1 to set the mode
to Wired.
2
1
Select the same channel the controller is on to automatically pair.
Press the Menu button on MDR-ACI, then navigate to MDR Settings>Channel.
2
1
Navigate to WIRELESS>FIND RECV to scan for active receivers and automatically pair. The
LED on the controller will turn green once paired.
Press the MENU button on the controller.
2
1
