5 Installation of generato
340-1560-12.65-07
1
2
3
Inserting the generator (view: service ladder; left)
Inserting the generator
j WARNING
Risk of crushing by falling
generator
• Only use industrial trucks that
are suitable for the weight (for
information on the lifting
equipment, refer to on page 9).
• Do not remain under or put your
hands beneath the generator
when it is raised.
• Fasten the generator plate
without delay.
In emergency: Provide first aid.
Consult a doctor immediately.
Set the generator plate with the generator
screwed onto it on a suitable industrial
truck so that the fastening points of the
generator plate are accessible from below.
Move the generator plate into the
machine.
Screw in all hexagon bolts (2) with wash-
ers (1) into the uppercarriage (3) loosely.
12.65-SA10403-en-110808 Version 11.08.2008 21 (60)
