19
2.3.2 Timing Table Chart
Mode Resolution H-Freq. (KHz)
Bandwidth
(MHz)
Polarity
H V
1 VGA 720x400 70Hz 31.47 28.322 - +
2 VGA 640x480 60Hz 31.47 25.175 - -
3 MAC 640x480 66Hz 35 32.24 - -
4 VESA 640x480 72Hz 37.86 31.5 - -
5 VESA 640X480 75Hz 37.5 31.5 - -
6 VESA 800x600 56Hz 35.16 36 + +
7 VESA 800x600 60Hz 37.88 40 + +
8 VESA 800x600 75Hz 46.88 49.5 + +
9 VESA 800x600 72Hz 48.08 50 + +
10 MAC 832x624 75Hz 49.72 57.283 - -
11 VESA 1024x768 60Hz 48.36 65 - -
12 VESA 1024x768 70Hz 56.48 75 - -
13 VESA 1024x768 75Hz 60.02 78.75 + +
14 SXGA 1280x1024 60Hz 64 108 + +
15 SXGA 1280x1024 75Hz 80 135 + +
16 SXGA 1152x864 75Hz 67.5 108 + +
17 SXGA 1280x960 60Hz 60 108 + +
18 WXGA+ 1440x900 60Hz 56 106.5 - +
19 WXGA+ 1440x900 75Hz 70.6 136.75 - +
20 WSXGA+ 1680x1050 60Hz 65.2 146 - +
21 WSXGA+ 1680x1050 75Hz 82.3 187 - +
22 VESA 1280x 768 60Hz 47.776 79.5 - +
23 HD 1920X1080 60Hz 67.5 148.5 + +
Note: If input H-display > 1920 pixel or V-display > 1080 lines or V-Sync >76Hz, then
OSD shall display warning out of range.
