TES APM-22 User Manual

6
1.1 Overview
The APM-22 series is a 22” touchscreen monitor that builds to withstand commercial
grade open frame monitor, with stylish thin cable management bracket and versatile
design APM-22 is an exceptional choice for applications for all business sectors and well
suited for point-of-sales, point-of-information, point-of-service and interactive signage.
1.2 Feature
 Cable management bracket design for easy organize cable.
1.3 Specifications
LCD Touch Panel
Size 22” TFT LCD
Brightness
250 cd/m
2
(Non-touch screen)
212 cd/m
2
(P-CAP)
Number of Pixels 1920 (H) × 1080 (V)
Touch Type P-CAP/ 10 points
Environment
Compliance IPX0
Operating Temperature
0°C ~ 40°C
Storage Temperature
-20°C ~ 60°C
Operating Humidity 20% ~ 80% RH, non-condensing
Mounting VESA 100 mm x 100 mm
Dimension (W x H x D) 517.0 mm x 312.0 mm x 42.4 mm
Net Weight 4.4 kg
Gross Weight 6.3 kg

TES APM-22 Specifications

General

Brand	TES
Model	APM-22
Category	Monitor
Language	English
