INSTALLATION
Product Description
NOTE
Note: The actual model you purchased might differ. Please see the product you purchased in kind prevail.
Power cord
Top board
Control panel
Door
Air inlet
Base filter
Maintenance cover
Water container
Drum
Door filter
Remove the drain
hose from the
housing drawer.
Insert the drain
hose and the
external drainage
hose into the
connector.
Put the hose holder on the washing basin or any other sink.
Accessories
The following parts are optional for specific models.
If your dryer has following parts, please wear gloves and install them as per the instruction below.
Installation
Hose holder
Condensing drain hose
Connector
