45
TECHNICAL CHARACTERISTICS OF ABSOLUTE
CLASSIFICATION Device with internal power source
INTENDED USE Muscular abdominal stimulation
POWER SUPPLY
Rechargeable 3.7 V, 500 mAh lithium-polymer (LiPo) battery
PULSE REPETITION FREQUENCY 2 -150 Hz
IMPULSE BREADTH 80-325 uS
MAXIMUM ENERGY DELIVERED PER PULSE 3.50 mJ/impulse
MAXIMUM PEAK POWER 5.4 W/impulse
MAXIMUM CONTINUOUS POWER 650 mW
AVERAGE OUTPUT CURRENT AT MAX. FREQUENCY
10.2 mA
AVERAGE OUTPUT CURRENT AT MIN. FREQUENCY
70 μA
MAX. PEAK OUTPUT CURRENT 110 mA
PULSE SHAPE Square symmetrical biphasic waveform
BELT LENGTH 120cm
CHANNELS 2 independent and individually adjustable channels,
each insulated electrically from the other
ALL THE PARAMETERS SHOWN IN THE TABLE REFER TO EACH INDIVIDUAL CHANNEL, WITH A TYPICAL CHARGE OF 500 OHM
BATTERY RECHARGING
INPUT POWER SUPPLY 5Vdc-500 mA
RECHARGING CABLE USB 2.0 with micro-B connector
THE BATTERY CANNOT BE SUBSTITUTED BY THE USER
info@tesmed.com
+39 035 662660
every working day from 8.30 am to 12.30 am and from 1.00 p.m. to 5.00 pm
WhatsApp Tesmed
Fast Check Video
+ 39 345 6979093
Information on use and technical assistance:
@
If appropriate, it is possible to send a short video concerning
the device, to demonstrate any operating problems - the mes-
sage must be accompanied by a brief written explanation, with
a screen of the order number and the date of purchase. Servi-
ce active on working days and hours.
A copy of the manual in electronic format can be obtained on the tesmed.com
website at the INFORMATION AND MANUALS page by selecting Manuals
