2 Overview
The base F1 unit consists of a Windows-based tablet PC with installed soware. The
probe has a 52-element matrix transducer which connects to an internal DSP board lo-
cated within the RSWA. Two removable batteries provide up to 9–12 hours of run time
when disconnected from a power source. A charger/AC adapter provides power for
simultaneous device operation and battery charging. The device is designed with a
ruggedized case to provide protection against shock and mechanical damage.
1. F1 Tablet
2. Probe
3. Batteries
4. Shoulder strap
5. RF remote control
6. Charging cable
7. Charger/AC adapter
