§8 Performance and specifications
12
§8 Performance and specifications
8-1 Type Drop tester
8-2 Model DT-202
8-3 Specified performance
1) Maximum specimen size 150mm in width
2) Maximum weight of specimen 2kg
3) Drop height range 250 ~ 2200mm
4) Drop height setting Setting by scale and setting pointer
5) Fixing of specimen By pneumatic cylinders
6) Floor area for installation 600mm in width × 500mm in depth
7) Tester dimensions 600mm in width×500mm in depth×2382mm in height
8) Tester weight approx. 110kg
9) Painting color 《Body》Munsell code 10B5/10
(Japan Painting Industrial Association B69-50T)
《Control unit》Munsell code N9.5
(Japan Painting Industrial Association BN-95)
10) Feed power supply 100VAC, Single-phase, 5A
(Correspond from 100VAC to 240VAC)
11) Air source 0.49MPa or higher
12) Ambient temperature range 5～35℃
(JIS standard: Temperature condition at test places Class 4)
For the maximum specimen size, see Fig.7.
250-500mm: In this range specimen can be just released from the setting height while chuck itself would
stay at setting height..
