3 Specifications
6
3 Specifications
3.1. Use
The testo 570 is a digital manifold for commissioning, maintenance
and service work on refrigeration systems and heat pumps. It can
be used for fault diagnose and online measurements on
refrigeration systems and heat pumps. The testo 570 is only to be
used by qualified expert personnel.
With its functions the testo 570 replaces mechanical manifolds,
thermometers and pressure/temperature charts. Pressures and
temperatures can be applied, adapted, tested and monitored.
Its scope of functions can be considerably extended by means of
extensive, separately available accessories, e.g. various
temperature sensors, clamp probe, oil pressure probe,
PC software.
The testo 570 is compatible with most of the non-corrosive
refrigerants, water and glycol. The testo 570 is not compatible with
ammoniac refrigerants.
Then product must not be used in explosive environments!
3.2. Technical data
Feature Values
Measurement
parameters
Pressure: kPa/MPa/bar/psi
Temperature: °C / °F / K
Vacuum: hPa / mbar/ Torr / inH
2
O / Micron /
inHg / Pa
Current: A
1
Measuring sensor
Pressure: 2 x pressure sensor
Temperature: 3 x NTC
Measuring cycle 0.75 s
Connections
Pressure connections: 3 x 7/16" UNF+ 1x
5/8“
NTC measurement
Interfaces 3x Mini-DIN, 1x Mini-USB, 1 x IR
1
via clamp probe (optional accessory)
