34
3. Measuring in accordance with the previous example
Plug in the humidity probes on location and switch on the measuring instrument.
Set the location (in this case “heater”) at the top right of the display using the arrow buttons. Set
the function display in the top left to “Store symbol” (disk symbol).
In the case of the following probes the instrument has to be switched on since the time until a
reading is available is too long or the readings may be incorrect:
→ CO and pressure probe (10, 100 mbar)
(due to automatic initialisation when switched on)
→ CO
2
The instrument should be switched off if measuring series > 2 min (protects the battery).
The instrument switches on automatically to measure.
Switch on the instrument following automatic measuring. You will find the
“Ambient air office 2” log “5:00 26.12.97” in the main menu under MEMORY - READOUT .
Confirm selection with .
and contain further information on this log (max, min,...).
Using the function button, a log can be deleted from the instrument memory. This
button is only active if a program is not stored, if necessary the measuring program has to be
deleted.
Confirm by pressing
in
MEMORY -REORGANIZE
.
Then print via the button.
When printing out a measurement series you can choose whether you wish to print the series in
table form or as a diagram.
If printed in table form all of the parameters (e.g. °C, %RH, td°C) are printed.
If printed in diagram form a maximum of 2 parameters can be included in one diagram. You are
asked automatically in the display which parameters are to be shown in the diagram.
Select the first required parameter and
confirm with .
Sel
ect the second required parameter in the same way.
For the safe transmission of large amounts of data put on the attachable printer and switch on.
Delete
Info
Automatic storing
%
°C
td°C
td°C
