5 First steps
21
8. Press function key [Apply].
- The information Restart instrument appears.
9. Press [
].
- The instrument switches off.
> To switch on the instrument: Press [ ].
Switch the imager on/off
1. Remove protection cap from the lens.
2. Press [
].
- The start screen appears on the display. The type designation
of the imager and the firmware version are shown.
- The measurement view is opened after the warm-up period.
- The imager performs an automatic zeroing approx. every 60
sec. This can be recognized by means of a "click". The image is
frozen briefly when this occurs.
> To switch off: Press [
].
- The display goes out and the imager is switched off.
Manually focusing the image
> Turn Rotating ring of the lens until the image is in focus.
Record (freeze/save) image
1. Press [Trigger].
- The image is frozen (fixed image).
If the image is to be saved, the desired storage location can be set
using the left [Folder] quick select button, see Select the storage
location (folder), page 37.
• Infrared image or infrared/real image is shown: Infrared image
is saved, real image is saved in the same file as an attachment
to the infrared image (even when saving in infrared image
mode)
1
.
• Real image is shown: Real image is saved.
2. Save image: Press [Trigger] again, or: Press [OK].
or
Discard image: Press [ESC].
1
All saved images are shown in picture-in-picture mode in the gallery.
