6 Using the product
42
Task Actions/description
Manually set the values
for the ambient
temperature
(Temperature), ambient
humidity (Humidity) and
distance between the
imager and the object to
be measured (Distance
to subject).
> , .
Apply entries.
> .
Solar
To detect and document failures in photovoltaic systems, the solar
function can be selected. The sun's radiation intensity measured
(with an external instrument) can be entered for documentation
purposes. This value is saved with the IR- image.
If this function is activated, the entered value for the radiation
intensity is displayed (top left).
Task Actions/description
Open Solar input screen.
> | | Measurement | Solar.
Activate solar functions.
> Active.
> To deactivate, touch the button
again.
Manually set the value for
radiation intensity
(Temperature).
> , .
Apply entries.
> .
