TESTO 890 User Manual

6 Using the product
51
The sequences can be saved in various formats:
• BMT files:
sequence of individual image files (thermal images),
saved in a folder, folder name starts with SQ. Image
marks placed prior to recording (measuring points and
profile lines) are also saved as image data and cannot
be subsequently changed or deleted.
The individual thermal images of the sequence can be
displayed and analysed.
• VMT files (full radiometric video): video file in which
image data, measuring values and image marks are
saved, file name starts with SQ.
Saved files can be played back in testo IRSoft and
subsequently analysed over time by adding or changing
image marks.
The playback speed (frames per second) corresponds
to the video frequency of the camera, if the system
environment supports this frequency (see system
requirements), but max. 25 Hz.
If the Humidity and / or SuperResolution functions are enabled,
when the sequence assistant is called up they are disabled. These
functions are enabled once again when you exit the sequence
assistant.
Task Actions/description
Call up
function
> | | Assistants | Sequence
Capturing.
Set recording
parameters
A sequence is configured using the following
parameters:
• Format:
VMT (video file) or BMT without / with Real
image (images are saved in a container folder
and can be edited individually).
• Start:
Manual (when the shutter button is pressed),
Countdown (automatic start after expiration of
the set time), Max. temperature > (automatic
start following upper temperature deviation in
the overall image), Min. temperature <
(automatic start following lower temperature
deviation in the overall image), Range: Max.
temperature > (automatic start following upper
temperature deviation within the range
selection), Range: Min. temperature <
