6 Using the product
111
Designation Explanation
Automatic scale Specification as to whether the program
should perform the scaling of the value
axis.
Range of values
from ... to
Manual entry of the range of values if the
Automatic scale is deactivated.
Division Automat. Specification that the program should
perform the division of the axis.
Division Manual Specification that the division of the axis
should be performed manually.
Grid [<], [>] (if
automatic division is
activated)
Decrease or increase the division of the
axis by clicking on [<] or [>].
Interval (if manual
division is activated)
Manual entry of the grid.
Pos: 140 /TD/Produ kt verwenden/testo Sa veris/05a-3 Achsei nstellungen/07 Zeitac hse @ 0\mod_11939995441 99_79.docx @ 5704 @ 5 @ 1
Settings for the time axis
> With the right mouse button, click on the time axis in the
diagram.
- The Adjust time axis dialogue is shown.
