REMOVING THE PANELS
1
PANELLED BATHTUBS ONLY
Bathtub with 3 panels Bathtub with 2 panels Bathtub with 2 panels Bathtub with front panel Corner bathtub
with front panel
Lever the panels off at the points indicated, using a screwdriver (A), and detach (B) from the retaining clips.
Remove the panels in the sequence indicated: 1-2-3.
Examples of panelled tubs
LEVELLING THE TUB
2
Position the bathtub in the selected place and level up, first by
adjusting the outermost feet, then bringing the middle feet into
contact with the floor
.
Make the adjustment so as to leave a distance of 15 mm
minim
um between the floor and the bottom edge of the panel
to allow for ventilation of the whirlpool system.
9
GB
