Circuit Module Physical Layout, Bill of Materials and Schematic
www.ti.com
12
SLUUBF5–April 2016
Submit Documentation Feedback
Copyright © 2016, Texas Instruments Incorporated
bq27220EVM-744 Evaluation Module
4.2 Bill of Materials
Table 5 lists the BOM for this EVM.
Table 5. bq27220EVM-744 Bill of Materials
Designator Qty Value Description Package Reference Part Number Manufacturer Alternate Part
Number
Alternate
Manufacturer
!PCB 1 Printed Circuit Board PWR744 Any - -
C1 1 2.2uF CAP, CERM, 2.2 µF, 16 V, +/- 10%, X5R, 0805 0805 0805YD225KAT2A AVX
C2 1 1uF CAP, CERM, 1 µF, 16 V, +/- 10%, X5R, 0402 0402 C1005X5R1C105K050BC TDK
C3 1 0.47uF CAP, CERM, 0.47 µF, 6.3 V, +/- 10%, X5R, 0402 0402 GRM155R60J474KE19D Murata
J1 1 Header (friction lock), 100mil, 4x1, R/A, TH 4x1 R/A Header 22-05-3041 Molex
J2, J3, JP1, JP2 4 Header, 100mil, 2x1, Tin, TH Header, 2 PIN, 100mil, Tin PEC02SAAN Sullins Connector
Solutions
J4, J6, J7 3 Terminal Block, 6A, 3.5mm Pitch, 2-Pos, TH 7.0x8.2x6.5mm ED555/2DS On-Shore Technology
J5 1 Terminal Block, 6A, 3.5mm Pitch, 3-Pos, TH 10.5x8.2x6.5mm ED555/3DS On-Shore Technology
R1 1 0.01 RES, 0.01, 1%, 0.25 W, 0805 0805 WSL0805R0100FEA18 Vishay-Dale
R2 1 1.8Meg RES, 1.8Meg ohm, 5%, 0.063W, 0402 0402 CRCW04021M80JNED Vishay-Dale
R3 1 5.1k RES, 5.1k ohm, 5%, 0.063W, 0402 0402 CRCW04025K10JNED Vishay-Dale
R4, R5 2 10.0k RES, 10.0 k, 1%, 0.125 W, 0805 0805 CRCW080510K0FKEA Vishay-Dale
TP1, TP2, TP3,
TP4, TP5
5 SMT Test Point, Compact, SMT Testpoint_Keystone_Compact 5016 Keystone
U1 1 System-Side CEDV Fuel Gauge, YZF0009-C01 YZF0009-C01 BQ27220YZFR Texas Instruments BQ27220YZFT Texas
Instruments
Notes: Unless otherwise noted in the Alternate PartNumber and/or Alternate Manufacturer columns, all parts may be substituted with equivalents.
