www.ti.com bq27220EVM Quick Start Guide
5
SLUUBF5–April 2016
Submit Documentation Feedback
Copyright © 2016, Texas Instruments Incorporated
bq27220EVM-744 Evaluation Module
2.6 PC Interface Connection
The following steps configure the hardware for interface to the PC:
1. Connect the bq27220-based EVM to the EV2300 or EV2400 using wire leads as shown in Table 4.
2. Connect the PC USB cable to the EV2300 or EV2400 and the PC USB port.
Table 4. Circuit Module to EV2300 or EV2400 Connections
bq27220EVM EV2300 EV2400
SDA SDA SDA
SCL SCL SCL
VSS VSS VSS
J9 Short Open
J10 Short Open
The bq27220EVM-744 is now set up for operation.
