4.2 Layout
The layout source files for the LAUNCHXL-F280049C are provided in
C2000Ware_<version>\boards\LaunchPads\LAUNCHXL_F280049C\A\design files. The F28004x LaunchPad was created using Altium Designer
17. The gerber files are also provided in the same directory.
4.3 BOM
The BOM for the LAUNCHXL-F280049C is provided in C2000Ware_<version>\boards\LaunchPads\LAUNCHXL_F280049C\A.
4.4 LAUNCHXL-F280049C Board Dimensions
Figure 12 is a dimensional drawing of the F28004x LaunchPad that shows the location of selected features of the board as well as the component
locations.
