C2000™ Piccolo™ F28004x Series LaunchPad™ Development Kit
1 Board Overview
1.1 Kit Contents
The Piccolo F28004x Series LaunchPad Development Kit contains these items:
• C2000 Piccolo F28004x Series LaunchPad development board (LAUNCHXL-F280049C)
• USB micro-B plug to USB-A plug cable
• Two LaunchPad Stickers
1.2 Features
The F28004x LaunchPad has these features:
• C2000 Piccolo Series F280049CPZS microcontroller
– Enabled for InstaSPIN-FOC™ motor control and Configurable Logic Block (CLB) capability
• On-board XDS110 debug probe
• Two user-controlled LEDs
• One microcontroller reset switch
• Selectable power domains:
– USB (isolated)
– BoosterPack
– External power supply
• CAN connectivity with on-board CAN transceiver
• Two independent Enhanced Quadrature Encoder Pulse (QEP)-based encoder connectors
• Separate FSI connector
• Two independent BoosterPack XL standard connectors featuring stackable headers to maximize
expansion through the BoosterPack ecosystem
1.3 Specifications
Table 1 summarizes the F28004x LaunchPad specifications.
Table 1. LAUNCHXL-F280049C Specifications
Parameter Value
Board Supply Voltage
5 V
DC
from one of the following sources:
• Debug USB (USB101) USB Micro-B cable connected to PC or other compatible
power source.
• BoosterPack 1
• BoosterPack 2
• Auxiliary power connectors
Dimensions 6.15 in x 2.3 in x .425 in (15.62 cm x 5.84 cm x 10.8 mm) (L x W x H)
Break-out Power Output
• Optional 5 V
DC
to BoosterPacks, current limited by LMR62421. Nominal rating 2.1
Amps. Board input power supply limitations may also apply.
• 3.3 V
DC
to BoosterPacks, limited by output of TPS79601 LDO. This 3.3-V plane is
shared with on-board components. Total output power limit of TPS79601 is 1
Amp.
Assumed Operating Conditions
This kit is assumed to run at standard room conditions. The EVM should run at
approximately standard ambient temperature and pressure (SATP) with moderate-to-
low humidity.
