Controller Area Network (CAN)

void ROM_CANBitTimingGet (uint32_t ui32Base, tCANBitClkParms ∗psClkParms)

void ROM_CANBitTimingSet (uint32_t ui32Base, tCANBitClkParms ∗psClkParms)

void ROM_CANDisable (uint32_t ui32Base)

void ROM_CANEnable (uint32_t ui32Base)

bool ROM_CANErrCntrGet (uint32_t ui32Base, uint32_t ∗pui32RxCount, uint32_t

∗pui32TxCount)

void ROM_CANInit (uint32_t ui32Base)

void ROM_CANIntClear (uint32_t ui32Base, uint32_t ui32IntClr)

void ROM_CANIntDisable (uint32_t ui32Base, uint32_t ui32IntFlags)

void ROM_CANIntEnable (uint32_t ui32Base, uint32_t ui32IntFlags)

uint32_t ROM_CANIntStatus (uint32_t ui32Base, tCANIntStsReg eIntStsReg)

void ROM_CANMessageClear (uint32_t ui32Base, uint32_t ui32ObjID)

void ROM_CANMessageGet (uint32_t ui32Base, uint32_t ui32ObjID, tCANMsgObject

∗pMsgObject, bool bClrPendingInt)

void ROM_CANMessageSet (uint32_t ui32Base, uint32_t ui32ObjID, tCANMsgObject

∗pMsgObject, tMsgObjType eMsgType)

bool ROM_CANRetryGet (uint32_t ui32Base)

void ROM_CANRetrySet (uint32_t ui32Base, bool bAutoRetry)

uint32_t ROM_CANStatusGet (uint32_t ui32Base, tCANStsReg eStatusReg)

6.2.1 Function Documentation

6.2.1.1 ROM_CANBitRateSet

This function is used to set the CAN bit timing values to a nominal setting based on a desired bit

rate.

Prototype:

uint32_t

ROM_CANBitRateSet(uint32_t ui32Base,

uint32_t ui32SourceClock,

uint32_t ui32BitRate)

ROM Location:

ROM_APITABLE is an array of pointers located at 0x0100.0010.

ROM_CANTABLE is an array of pointers located at ROM_APITABLE[18].

ROM_CANBitRateSet is a function pointer located at ROM_CANTABLE[16].

Parameters:

ui32Base is the base address of the CAN controller.

ui32SourceClock is the system clock for the device in Hz.

ui32BitRate is the desired bit rate.

Description:

This function will set the CAN bit timing for the bit rate passed in the ui32BitRate parame-

ter based on the ui32SourceClock parameter. Since the CAN clock is based off of the sys-

tem clock the calling function should pass in the source clock rate either by retrieving it from

ROM_SysCtlClockGet() or using a speciﬁc value in Hz. The CAN bit timing is calculated as-

suming a minimal amount of propagation delay, which will work for most cases where the

April 8, 2013 55
