Functional Description
www.ti.com
Table 2-4. X11 Breadboard Adapter Even-Numbered Pad GPIO and Signal Muxing (continued)
Digital Function (GPIOPCTL Bit Encoding)
MCU
Pin Port Analog
PIN
1 2 3 5 6 7 8 11 13 14 15
68 PF1 43 - - - - EN0LED2 M0PWM1 - - - - SSI3XDAT0 TRD1
70 PF2 44 - - - - - M0PWM2 - - - - SSI3Fss TRD0
72 PF3 45 - - - - - M0PWM3 - - - - SSI3Clk TRCLK
74 PA0 33 - U0Rx I2C9SCL T0CCP0 - - CAN0Rx - - - - -
76 PA1 34 - U0Tx I2C9SDA T0CCP1 - - CAN0Tx - - - - -
78 PP4 105 - U3RTS U0DSR - - - - - - - USB0D7 -
80 PP5 106 - U3CTS I2C2SCL - - - - - - - USB0D6 -
82 PJ0 116 - U3Rx - - - - - - - - -
84 PJ1 117 - U3Tx - - - - - - - - - -
86 PM7 71 TMPR0 U0RI - T5CCP1 - - - - - - - -
88 PM6 72 TMPR1 U0DSR - T5CCP0 - - - - - - - -
90 PM5 73 TMPR2 U0DCD - T4CCP1 - - - - - - - -
92 PM4 74 TMPR3 U0CTS - T4CCP0 - - - - - - - -
94 RESET
96 GND
98 3V3
16
Hardware Description SPMU365A–March 2014–Revised March 2014
Submit Documentation Feedback
Copyright © 2014, Texas Instruments Incorporated
