Bill of Materials
Table 4-1. Connected LaunchPad Bill of Materials (continued)
Item Ref Qty Description Mfg Part Number
RESET, USR_SW1, Switch, Tact 6mm SMT,
27 4 Omron B3S-1000
USR_SW2, WAKE 160gf
Tiva, MCU TM4C1294NCPDT Texas Instruments TM4C1294NCPDT
28 U1 1 128 QFP with Ethernet MAC
Texas Instruments XM4C1294NCPDT
+ PHY
Transformer, ethernet, 1 to 1.
29 U10 1 Pulse Electronics HX1198FNL
SOIC 16
Diode, 8 chan, +/-15KV, ESD
30 U13 1 Semtech SLVU2.8-4.TBT
Protection Array, SO-8
Connector, RJ45 NO MAG,
31 U14 1 TE Connectivity 1-406541-5
shielded THRU HOLE
IC 4CH ESD SOLUTION
32 U2, U3 2 Texas Instruments TPD4S012DRYR
W/CLAMP 6SON
Stellaris TIVA MCU
33 U20 1 Texas Instruments TM4C123GH6PMI
TM4C123GH6PMI
USB Micro B receptacle
34 U22 1 FCI 10118194-0001LF
right angle with guides
Fault protected power switch,
35 U4 1 Texas Instruments TPS2052BDRBR
dual channel, 8-SON
3.3V LDO TI TPS73733DRV
36 U5 1 Texas Instruments TPS73733DRV
fixed out 5V in
Samtec SHF-105-01-S-D-SM
Header 2x5, 0.050, SM,
37 U6 1
Don Connex
Vertical Shrouded
C44-10BSA1-G
Electronics
USB Micro AB receptacle.
38 U7 1 Right angle with through Hirose ZX62D-AB-5P8
guides
Samtec SSW-110-23-S-D
Header, 2x10, T-Hole Vertical
39 X6, X7, X8, X9 4
Major League
unshrouded stacking
SSHQ-110-D-08-F-LF
Electronics
40 Y1 1 Crystal 25 MHz 3.2 x 2.5 mm NDK nx3225ga-25.000m-std-crg-2
Crystal 16 MHz 3.2 x 2.5 mm
41 Y2 1 NDK NX3225GA-16.000M-STD-CRG-2
4 pin
Crystal, 32.768 KHz Radial Citizen Finetech
42 Y3 1 CMR200T-32.768KDZY-UT
Can Miyota
PCB Do Not Populate List (Shown for information only)
Capacitor, 0.1uF 16V,
43 C2 1 Taiyo Yuden EMK105B7104KV-F
10%, 0402 X7R
Screw, #4 x 0.625" Pan
Head, Sheet Metal,
44 H1, H4, H6 3 McMaster 90077A112
Phillips/Slotted
(for fan)
Resistor, 5.6k ohm,
45 R12, R13, R14 3 Panasonic ERJ-2GEJ562X
1/10W, 5%, 0402
46 R48 1 Resistor 0402 1% 52.3k Rohm TRR01MZPF5232
TP1, TP2, TP3, TP4, TP5,
TP6, TP7, TP8, TP9, Terminal, Test Point Miniature
47 17 Keystone 5000
TP10, TP11, TP12, TP13, Loop, Red, T-Hole
TP14, TP15, TP16, TP17
Header, 2x7, 0.100, T-Hole,
48 X1 1 Vertical, Unshrouded, 0.230 FCI 67997-114HLF
Mate
Valvano style bread board
49 X11A 1 connect. Right Angle Samtec TSW-149-09-F-S-RE
extended, 1 x 49 0.100 pitch.
valvano style breadboard
50 X11B 1 Samtec TSW-149-08-F-S-RA
header.
25
SPMU365A–March 2014–Revised March 2014 References, PCB Layout, and Bill of Materials
