3. Identification of parts
Figure 1.
1. Throttle lever
2. Blade
3. Screen
4. Shaft
5. Strap holder
6. V handle
7. Engine
Figure 2.
1. Spark plug
2. Air filter housing
3. Choke
4. Starting handle
5. Primer
6. Fuel tank
4. Fitting screen and handle
Fit screen using screws supplied.
Check screen is secure.
See figure 3.
Fit handle and ensure machine is balanced.
Ensure machine is easy to use
for the user.
See figure 4.
5. Switch from trimmer to bush clearer
Remove trimmer head - Figures 5, 6.
Fit holder (7) into trimmer gear wheel (9), and bushings (5) to secure shaft.
Unscrew twine head (8) clockwise.
NB: Keep trimmer head parts together.
Fitting blade – Figures 5, 6
4. Fit holder (7) into trimmer gear wheel (9), and bushings (5) to secure shaft.
5. Fit blade (6) and spacer (4) to shaft.
6. Fit washer and nut (2). Tighten securely anticlockwise.
Always ensure blade is secure. If in doubt, contact your nearest dealer.
Using the blade
- Keep blade in dense grass or weeds when stopping engine until rotation has
ceased.
- Always hold machine securely in both hands.
- Do not use if screen is incorrectly fitted and in poor condition.
- Always stop engine before removing any materials stuck in blade.
- Never attempt to touch or stop blade whilst it is rotating.
- A rotating blade can cause injury, as it will continue to rotate after the engine is
stopped or gas regulator activated. Always maintain control over the machine until
blade stops completely.
