Ricochet MT2 Addendum
ADD068 11
Ricochet™ Monitor
Ricochet™ Monitor now connects to Wintex™ using the “localhost” connection and the port number used in the "Connection Setup"
menu of Wintex detailed on the previous page. The default port number is 10010.
You must be connected to the panel with Wintex before this function will work.
Connection Details
Connecting to Ricochet™ Monitor
Using the "QuickConnect" button in Wintex™
Once connected to the panel via Wintex™ you can use the
"QuickConnect" button as detailed on the previous page.
Launching Ricochet™ Monitor and connecting
Launch the programme and click on the "Connect" button.
Expander Selection
Once connected you will be able to select which expander
you want to view information from with the new Expander
Selection pane. This pane will show all of the available
expanders by showing a raised button. Simply click on the
expander you wish to view the details and devices on, the
button will be depressed and green.
In the below example two expanders are available, and
expander 1 has been selected to view.
Additionally information about the expander is shown when
you hover over its button.
Device Information
The device information window now shows the expander
information, the device slot the zone number and any text
associated with the zone. The current status of the device is
also shown including whether the device is “Awake” or
“Asleep”.
Premier Elite SmartKey™ Information
The Premier Elite SmartKey™ information window has
changed, the expander and device number is shown, and the
User number and Name if programmed are also shown.
