GENERAL SPECIFICATIONS
Fig. 45 Vehicle Turning Clearance Diameter
Fig. 46 Vehicle Incline Specifications
TURNING CLEARANCE DIA.
Approx. 23.5 ft (7.2 m)
Ref Tur 7S
Maximum Recommended Side Tilt
25% or 14˚ Max.
Maximum Recommended Ramp Grade
25% or 14˚ Max.
