GB-12
JACOBSEN FAIRWAY 305 Series CG
SAFETY AND OPERATORS MANUAL
GB
6 CONTROLS
6.6 SPEED LIMITER
The speed limiter (A) is operated by pivoting the
lever under the footpedal. When positioned under
the footpedal the machine is limited to cutting
speed, when not under the footpedal transport speed
is availabe.
6.7 PARK BRAKES
Push the pedal forward (A) until it locks to set
parking brake. Release parking brake by pushing the
brake pedal at the same time lever (B) is pulled up.
6.8 HYDRAULIC LIFT LEVER
The cutting units can be raised and lowered by
control lever (A) situated on the right hand side of
the operators seat and can be operated as follows:
To lift: Move the lever backwards and hold in position
until the units are at the required height.
To lower: Move the lever forwards and hold in this
position, the units will lower to ground level. The
lever automatically returns to a neutral position when
released.
NOTE: If any unit is raised out of work then lowered
into work again the blades will not rotate until the
mow foot switch is depressed.
NOTE: The units will only lift and lower when the
engine is running.
