JACOBSEN FAIRWAY 305 Series CG
SAFETY AND OPERATORS MANUAL
GB
4 SPECIFICATIONS
4.1 ENGINE SPECIFICATION
TYPE: Kubota 28KW (38HP) @ 3000
RPM, 4 cylinder (in line) vertical
Diesel engine, 4 stroke, water
cooled, 1498cc (91.44 cu.in)
with 12V electric start.
Model: V1505-BBS-EC-1
Maximum Speed: 3000 ± 50 RPM (No load)
Idle Speed: 1500 RPM
Oil Sump Capacity:6.0 litres (10.56 Imp.pints)
Fuel: No. 2-D Diesel fuel (ASTM D975)
TYPE: Kubota 34.7KW (46.5HP) @
3000 RPM, 4 cylinder (in line)
Turbo charged Diesel engine, 4
stroke, water cooled, 1498cc
(91.44 cu.in) with 12V electric
start.
Model: V1505-TBS-1-S1
Maximum Speed: 3000 ± 50 RPM (No load)
Idle Speed: 1500 RPM
Oil Sump Capacity:6.4 litres (11.26 Imp.pints)
Fuel: No. 2-D Diesel fuel (ASTM D975)
4.2 MACHINE SPECIFICATION
Frame construction:Heavy duty formed steel chassis
with box section frame rails.
Cutting unit drive: Fixed displacement hydraulic
motors directly coupled to
cutting unit.
Transmission: Full time 4-wheel drive. Direct
coupled variable displacement
pump to direct coupled 29 cu in
front, 21 cu in rear wheel motors.
Speeds:
Cutting: 0 - 12km/h (0 - 7.5 mph)
FORWARD
Transport: 0 - 14km/h (0 - 8.5mph)
FORWARD
Reverse: 0 - 6.4km/h (0 -4 mph)
Steering: Hydrostatic power steering, with
adjustable tilt steering wheel.
Brakes: Hydrostatic braking with
mechanical type band parking
brakes, 260mm x 45mm
(10.25in x 1.75in) on front
wheels.
503YAWRIAF
0GCseireS
noitareleccAmrA/dnaH
level
HRroHLxaM
s/msnoitareleccA
2
qeAXqeAYqeAZ
636.0116.0026.0
eulaVtnanimoD636.0
503YAWRIAF
0GCseireS
ydoBelohW
noitareleccA
level
noitacoLroolF
s/msnoitareleccA
2
noitacoLtaeS
s/msnoitareleccA
2
xyzxyz
naeM10.01810.09640.010.08710.03330.0
SERUSSERPERYT
tcudorP
leehWtnorF leehWraeR
eziSeryTepyTeryTerusserPeryTeziSeryTepyTeryTerusserPeryT
504,503,052yawriaF
052RA
21-00.41x5.62
rp4carTartlUnatiTisp02-41rab73.1-00.1
8-00.01x02
rp4carTartlUnatiTisp02-41
rab73.1-00.1
Fuel Tank
Capacity: 45.4 litres (10 Imp. galls) 12 US
galls
Hydraulic Tank
Capacity: 37.8 litres (8.3 Imp. galls) 10 US
galls
Battery: Exide 093 (SAE 500)
4.3 DIMENSIONS
Width of cut: 2.94 metres (116in)
Overall width: 3.22 metres (126.8in)
Overall width: 2.52 metres (99.2in)
(transport)
Overall height: 1.6 metres (63in)
Overall length: 2.75 metres (113.4in)
Overall weight of
machine: 1515 kg (3340lb)
4.4 VIBRATION LEVEL
4.4.1 VIBRATION LEVEL
The machine was tested for whole body and hand/
arm vibration levels. The operator was seated in the
normal operating postion with both hands on the
steering mechanism. The engine was running and
the cutting device was rotating with the machine
stationary.
Standard ISO 5349: 1986 Mechanical vibration.
Guidelines for the measurement and the assessment
of human exposure to hand-transmitted vibration.
Standard ISO 2631-1: 1985 Evaluation of human
exposure to whole body vibration -- Part 1: General
requirements.
