24
JZT 2000
Series
SPECIFICATIONS
CONSTRUCTION:
Fabricated and welded or bolted 10-gauge, double-
layer steel top with 7-gauge side skirts. Full floating
design.
CUTTERDECK DRIVE SYSTEM:
Electric clutch/brake drives belt directly from engine
to center spindle of cutterdeck. No twists in drive
belt.
SPINDLES:
Top mounted and maintenance free, with 1" shaft in
precision machined, aluminum housing
ANTI-SCALP ROLLERS:
52" Cutterdecks - 6 Rollers
61" Cutterdecks - 7 Rollers
CUTTING HEIGHT & PRODUCTION:
Height: Electric actuator allows easy setting of cut
heights from 1-1/2” to 4-1/2” in 1/4” increments. “Set
and forget” feature allows height of cut to be set and
returned to without searching from operator position.
SPECIFIC TORQUES
BLADE BOLT TORQUE: 70 FT-LBS (95 Nm)
WHEEL HUB NUTS: 225 FT-LBS (237 Nm)
ENGINE CRANKSHAFT BOLT: 50 FT-LBS (68 Nm)
CUTTERDECKS
MODEL NUMBER
742221A, 742222A,
742227A
742223A, 742228A,
742233A
TYPE
Side Discharge Side Discharge
CUTTING WIDTH
52.5" (133 cm) 61" (155 cm)
WIDTH
N/A N/A
WIDTH (CHUTE UP)
56.25" (143 cm) 62" (157 cm)
WIDTH (CHUTE
DOWN)
64.5" (164 cm) 73" (185 cm)
BLADE
high lift
(low lift optional)
high lift
(low lift optional)
NUMBER OF
CUTTING UNITS
33
BLADE LENGTH
18" (46 cm) 21" (53 cm)
BLADE THICKNESS
.205" (5.2 mm) 0.25" (6.35 mm)
TIP SPEED
18585 ft/min
5665 m/min
@ 3600 Engine RPM
18850 ft/min
5745 m/min
@ 3500 Engine RPM
DAILY PRODUCTION
(8 hr @ 6 mph)
Up to 25.5 acres (10.3 ha) Up to 29.5 acres (11.9 ha)
