HE.9843_J © 03/2008 3
MAP 1
GB
Instruction Manual
4. Description of the battery operated electro-hydraulic pressing tool
4.1 Description of the components
The hydraulic tool type MAP 1 is a hand held tool and consists of the following components:
Table 1 (see pic.1)
Pos. Description Function
1 Pressing head Working unit to accommodate the pressing dies
2 Retract slide Bar to open the crimping dies in case of an error or emergency
3 battery lock Slide to unlock the battery
4 Battery rechargeable NiMH battery 9.6V
5 LED Battery charge control and indication of Service Intervals
6 Trigger Actuator to start the crimping cycle
7 Jaws interchangeable pressing jaws with multiple pressing geometries
8 Locking pin Pin with special lock to open/close the pressing head
9 Lock to hold the interchangeable dies in place
4.2 Brief description of the important features of the unit
The hydraulic unit incorporates an automatic retraction which returns the piston into its starting position when the
maximum force is reached.
The unit is equipped with a special brake which stops the forward motion of the drive rolls when the trigger (pic. 1, 6)
is released.
The MAP 1 has a very safe locking system to lock the interchangeable mini jaws.
The locking system for the interchangeable dies which fi t the jaws is very smooth and compact.
Availability of a wide spectrum of MAP jaws and interchangeable pressing dies which are common in the market
since ages.
