HE.9843_J © 03/2008 10

MAP 1

Instruction Manual

7. Technical Data

Type MAP 1

Weight incl. battery&jaws: approx. 2,5 kg

Pressing time: 3-4 s

Thrust force: 15 kN

Battery voltage: 9,6 V

Battery capacity: 2,0 Ah NiMH (RAM2)

Battery charging time: approx. 40 min., resp. 15 min. with fast-charger

Cycles/battery: 90 cycles at NW 20

Ambient temperature: -20°C to +40°C

Hydraulic oil: Shell Tellus T 15

Sound level: 70,6 dB (A) in a distance of 1m

Vibrations: < 2,5 m/s²
