HE.9843_J © 03/2008 6
MAP 1
GB
Instruction Manual
5.2 Explanation of the application range
The MAP 1 is a hand guided pressing tool to mount fi ttings on multi Layer, copper and stainless steel type plumbing
tubes with Ø 12 to 32 mm. The unit is not supposed to be restrained in a vise. It is not allowed to use the tool in a
stationary application.
The tool is not designed for continued crimping operations. After a sequence of approximately 50 completed crimps
you have to make a break of 15 min. to give the tool time to cool down.
Attention
Too intensive use can cause heat damages for the tool
Attention
During the operation of electric engines sparks can occur which might ignite highly infl ammable or explo-
sive liquids and materials
Attention
Electric tools should not be operated in pouring rain or under water.
5.3 Mounting instructions
Please reference the assembly manual of the systems supplier before mounting the fi ttings on the tubes. In order to
safeguard a proper pressing and to guaranty a safe and reliable handling the machine must only be operated with
pressing jaws/dies recommended by the provider of the tube system and/or the tool manufacturer. If the markings on
the tool and pressing jaw do not match respectively if there are no assembly instructions the user has to contact the
provider of the system to request a compatibility statement.
Attention
Do not use bent or damaged pressing jaws.
Remark
As the tool manufacturer we offer perfectly designed pressing jaws for all known systems and tube dimen-
sions. Special designs and customer solutions upon request.
