7. signal power starts at 10% and the receiver sensitivity starts at
5% and automatically increases until a received signal from the
blank wall without the reflector of between 5 and 7% is
achieved, it will then stop
if you are covering a distance of over 50 meters you should be
achieving signal power of over 60%, if you are receiving less it’s
possible that you are picking up a reflection from something
other than the target blank wall. By moving the beam
(looking at the wall) left (x-) right (x+) up (y+) and down
(y-) you can move the beam away any obstacles to
achieve higher signal power
8. Once you are happy with the power readings press enter
and confirm by pressing the right key. The manual alignment
menu will appear press enter to enter.
you will now seen this screen
Y +
X+
X -
Y -
obstacle
roof line
target wall
received signal
press enter in
pre-alignment and then
confirm by pressing the
right key
press enter to
enter manual
mode
7
