The Fire Beam firebeam - Manual Alignment Adjustments

Y +
X+
X -
Y -
Y -
40 steps = 1 degree of movement
Adjustments can now be made to the X and Y axis by using the
left(
x-), right(x+), up(y+), down(y-) keys. Looking at the reflector
this will move the beam across the reflector like so
(40 steps = 1degree) (you can hold the key down for faster increments)
in the example above moving the y axis down(y-) results in a greater
% air quality
Wait for x / y values to finish moving to asses your AQ result
beam head
reflector
Press enter to exit manual mode and enter Auto Alignment
Try and achieve as good a result as possible - it must be
over
40% or auto align will abort. (the better the result the shorter the
auto align time will be - a result over 100 is good!)
10. Having received a AQ reading of over 40% in manual mode
press enter to exit manual and enter again to enter
auto align
ment
press enter and the beam head will automatically align on the reflector
9
