The Renovator Transforma 24 - Work Platform Configuration Instructions

13
Figure G-1
1. Adjust the bolt tightness
untilbracketsmovestify.
(See Figure G-1).
Figure G-2
2. Adjusttheplatformtot
the ladder rung.
(See Figure G-2).
Figure G-3
3. Place platform at required
height.
(See Figure G-3).
Figure G-4
4. Slide platform in and
carefully climb up above
the platform.
(See Figure G-4).
Figure G-6
6. Ensure the platform is
securely in place by
applying light pressure with
your foot before putting
your full weight on it.
(See Figure G-6).
Figure G-5
5. Slide the platform back with
the front of your foot
(See Figure G-5) until the
forward end of the platform
rests against the rung.
G. WorkPlatformCongurationInstructions
